TECHNICAL DETAILS

1 FLOOR       2 WALLS        3 ROOF


CONSTRUCTION DETAILS

1 FLOOR

F01- Laminate Flooring
F02 - Underlay
F03 - Electric Underfloor Heating
F04 - Decoupling Membrane
F05 - OSB
F06 - Joist
F07 - Insulation
F08 - Damp Proof Membrane
F09 - Rodent Barrier
F10 - Steel Frame
F11 - Pile Cap
F12 - Screw Pile

2 WALLS

W01 - Nordic Spruce Triple Profile Cladding
W02 - Horziontal treated Batten
W03 - Vertical treated Batten
W04 - Breather Membrane
W05 - Structural insulated Panel
W05.1 - OSB
W05.2 - Insulation
W06 - Vapour Barrier
W07 - Internal Batten
W08 - Plasterboard
W09 - Skim Coat
W10 - Skirting
W11 - Mesh

3 ROOF

R01 - Aluminium Fascia
R02 - PVC Roofing Membrane in a Grey Finish
R03 - Structural insulated Panel
R03.1 - OSB
R03.2 - Insulation
R04 - Vapour Barrier
R05 - OSB
R06 - Joist
R07 - Plasterboard
R08 - Skim Coat
R09 - Upstand


GENERAL FLOOR PLAN AND ELEVATIONS MATERIALS

CD - Composite Decking
CS - Steps
BS - Brise Soleil made from Cedar and Aluminium

FACADE
F1 - Nordic Spruce Triple Profile Cladding

WINDOWS AND DOORS
W1 - 2 Panel Sliding Window
W2 - 3 Panel Sliding Window
Wx - 3 Panel Sliding Window or Solid Wall
W3 - Tilt and Turn Window
GD - Glazed Door
ED - Solid Panel Door

Engineered Spruce Wood Frames

Double glazed sealed Units with toughened Glass
U-value 1.1 W/(m²K)


TERRAINS

Traditionally construction is time consuming, expensive and unpredictable. What’s more, the perfect site for your mobile home might be impossible because of terrains that slope down to a lake for example, or uneven ground that can’t be easily levelled.
We have found a number of solutions to this issue by developing a system that allows you to site your mobile home wherever you want it without incurring costs for preparing the site.
This includes a wide choice of different terrains and ensures that your idyllic retreat is set in your ideal location.




KITCHEN DRAWINGS

APPLIANCES

A01 - Stainless Steel Cooker Hood 60cm
A02 - Built In Electric Oven 60cm
A03 - 4 Zone Induction Hob
A04 - Microwave
A05 - Dishwasher 45cm
A08 - Fridge and Freezer Tower (70/30)

FITTINGS

F23 - Monobloc Swan Neck Mixer Tap
F24 - Kitchen Sink in Granite Composite 55x43cm
F19 - Square Edge Laminate Worktop

KITCHEN DRAWINGS

UNITS

U01 - Full-Height Wall Unit 45cm
U02 - Full-Height Wall Unit 20cm
U03 - Microwave Housing Unit 60cm
U04 - Hob Wall Unit 60cm
U05 - Full-Height Wall Unit 30cm
U08 - 2 Drawer Base Unit 80cm
U09 - Built-Under Oven Base Unit 60cm
U10 - 4 Drawer Base Unit 30cm
U11 - 2 Drawer Base Unit 60cm

FITTINGS

F19 - Square Edge Laminate Worktop
F20 - Backboard Glass  60x85.9cm
F23 - Monobloc Swan Neck Mixer Tap
F24 - Kitchen Sink in Granite Composite 55x43cm
F28 - Laminate Backboard 60cm high

APPLIANCES

A01 - Stainless Steel Cooker Hood 60cm
A02 - Built In Electric Oven 60cm
A03 - 4 Zone Induction Hob
A04 - Microwave
A05 - Dishwasher 45cm
A08 - Fridge and Freezer Tower (70/30)


DELUXE EN-SUITE
FLOOR PLAN AND ELEVATIONS

01 - Wall Hung WC
03 - Tall Basin Mixer
04 - Lay-on round Washbasin 40cm diameter
05 - Shower Column - Cool Touch
07 - Toilet Roll Holder
08 - Robe Hook
09 - Stainless Steel standing Toilet Brush
10 - Mirror
12 - Roof window 40x110cm
14 - Ceramic Tile 60x40cm
15 - Full length Mirror 235x60cm
16 - Shower Shelf
17 - Towel Ring
18 - LED Strip 2700K in recessed Channel
19 - Electric Towel Rail
20 - Linear Drain
21 - Flush Plate
22 - Recessed Shelf

F03 - 1 Drawer Wall 60cm

FITTINGS
F08 - Square Edge Laminate Worktop

01 - Wall Hung WC
05 - Shower Column - Cool Touch
07 - Toilet Roll Holder in Matt Black
09 - Stainless Steel standing Toilet Brush
10 - Mirror
12 - Roof Window 40x110cm
13 - Fire Panel A1 painted
14 - Ceramic Tile 60x40cm
16 - Shower Shelf
21 - Flush Plate
22 - Recessed Shelf
23 - Wall Cabinet. Doors covered in Mirrors




SHOWER ROOM
FLOOR PLAN AND ELEVATIONS





02 - Close Coupled WC
03 - Tall Basin Mixer
04 - Lay-on round Washbasin 40cm diameter
05 - Shower Column - Cool Touch
07 - Toilet Roll Holder
08 - Robe Hook
09 - Stainless Steel standing Toilet Brush
10 - Mirror
11 - Translucent Glass Screen 8mm toughened
14 - Ceramic Tile 60x40cm
16 - Shower Shelf
17 - Towel ring
19 - Electric Towel Rail
20 - Linear Drain

F01 - Extra Tall Larder with 2 Drawers 60cm
F02 - 2 Drawer Base Unit 80cm
F08 - Square Edge Laminate Worktop

WT - Hot Water Tank




WARDROBES
FLOOR PLANS AND ELEVATIONS



W01 - 200 x 58 x 236 cm
1 x Wardrobe Frame 100 x 58 x 236 cm
2 x Wardrobe Frame 50 x 58 x 236cm
3 x Drawer 100 x 58 x 16 cm
3 x Drawer 50 x 58 x 16 cm
2 x Pull-out Tray 100 x 58 cm
2 x Pull-out Tray 50 x 58 cm
2 x Shelf 100 x 58 cm
3 x Shelf 50 x 58 cm
1 x Clothes Rail 100 cm
2 x Clothes Rail 50 cm
4 x Wardrobe Door 235.5 x 49.5 cm
4 x Wardrobe Door Handle





W02 - 175 x 58 x 236 cm
1 x Wardrobe Frame 100 x 58 x 236 cm
1 x Wardrobe Frame 75 x 58 x 236 cm
3 x Drawer 100 x 58 x 16 cm
2 x Pull-out Tray 100 x 58 cm
2 x Shelf 100 x 58 cm
1 x Shelf 75 x 58 cm
1 x Clothes Rail 100 cm
1 x Clothes Rail 75 cm
2 x Wardrobe Door 235.5 x 49.5 cm
2 x Wardrobe Door 235.5 x 37 cm
4 x Wardrobe Door Handle

Doors: Melamine Particleboard



W03 - 100 x 58 x 236cm
1 x Wardrobe Frame 100 x 58 x 236 cm
3 x Drawer 100 x 58 x 16 cm
2 x Pull-out Tray 100 x 58 cm
4 x Shelf 100 x 58 cm
2 x Wardrobe Door 235.5 x 49.5 cm

W04 - 75 x 58 x 236 cm
1 x Wardrobe Frame 75 x 58 x 236 cm
3 x Drawer 75 x 58 x 16 cm
2 x Pull-out Tray 75 x 58 cm
4 x Shelf 75 x 58 cm

W05 - 175 x 58 x 236 cm
1 x Wardrobe Frame 100 x 58 x 236 cm
1 x Wardrobe Frame 75 x 58 x 236 cm
3 x Drawer 100 x 58 x 16 cm
2 x Pull-out Tray 100 x 58 cm
2 x Shelf 100 x 58 cm
1 x Shelf 75 x 58 cm
1 x Clothes Rail 100 cm
1 x Clothes Rail 75 cm

Doors: Melamine Particleboard




YOUR STYLE CHOICES

Take a moment to look at these three mood boards to ensure that your mobile home is finished and fitted out in the co-ordinated colour scheme that suits your taste perfectly. Your chosen colour scheme is applied throughout the mobile home’s interior.

CHARCOAL

Matt finishes and wood textures in charcoal black, for a sleek monochrome effect.

  1. Laminate Flooring (Dark)
  2. Walls and Ceilings Plasterboard painted Matt Black
  3. Aluminium Fascia in Matt Black
  4. Nordic Spruce Cladding coated in Matt Black
  5. Wooden Window Profiles in Matt Black
  6. Acoustic Slat Wall Coverings in Black
  7. Kitchen & Bathroom Worktops Black Laminate
  8. Kitchen & Bathroom Furniture Matt Black
  9. Doors, Skirting, Particle Board in Matt Black
  10. Metal Hardware, Steel or Aluminium in Black
  11. Black Ceramic Tile 60x40cm



CINNAMON

Combining wood textures with light colours and dark accents for a premium look.

  1. Laminate Flooring (Natural Oak)
  2. Walls and Ceilings Plasterboard painted White
  3. Aluminium Fascia in Matt Black
  4. Nordic Spruce Cladding with Natural Finish
  5. Wooden Window Profiles in Matt Black
  6. Acoustic Slat Wall Coverings in Walnut
  7. Kitchen & Bathroom Worktops Black Laminate
  8. Kitchen & Bathroom Furniture Matt Black
  9. Doors, Skirting, Particle Board in Matt White
  10. Metal Hardware, Steel or Aluminium
  11. Black Ceramic Tile 60x40cm




JASMINE

A lighter option that combines warm wood textures and cool grey/whites.

  1. Laminate Flooring (Light Oak)
  2. Walls and Ceilings Plasterboard painted White
  3. Aluminium Fascia in Matt Black
  4. Nordic Spruce Cladding with Natural Finish
  5. Wooden Window Profiles in Matt Black
  6. Acoustic Slat Wall Coverings in Walnut
  7. Kitchen & Bathroom Worktops White Laminate
  8. Kitchen & Bathroom Furniture Matt White
  9. Doors, Skirting, Particle Board in Matt White
  10. Metal Hardware, Steel or Aluminium
  11. Grey Ceramic Tile 60x40cm






Frequently asked questions

+ -

Do I need to get planning permission for my Mobile Home?

If planning permission is required, Rooms Outdoor offers a full planning consultancy service. This includes site surveys, technical drawings, creation and submission of your planning application, tracking and dealing with the local authority on your behalf.

+ -

Can my Mobile Home be moved?

Yes it can! A mobile home is a movable structure. It is constructed in a way that meets the typical and required mobility tests, for its category.

+ -

Is the delivery of my Mobile Home included in the price?

Your mobile home is manufactured 'ex works', with delivery to your chosen location to be organised through a specialist company. The transportation costs are not included in our prices, as they vary on the location and the complexity of your site.

+ -

Can my Mobile Home be installed on a sloping site?

Yes, your Mobile Home can be installed on various terrains, even on sloping ones. There are different solutions to this issue, that will allow your idyllic retreat to be set in the most ideal location.
